DSI Config
Fsync Width
– One Bit Clock
– One Subframe
– 50% Duty Cycle
Select the sync width.
Data Shift Cnt Set the data shift count value.
Data Shift Dir
–Left
–Right
Select the data shift direction.
Master Output
–On
–Off
Enable or disable the master clock output.
Word Length
Set the master clock word length value. The word
length cannot be less than the audio resolution.
– 8 to 32
Multiplier Set the multiplier value.
Sample Rate Set the sample rate value.
AES3/SPDIF
Level Set the output voltage level.
Resolution 8 to 24 Set the audio resolution value.
Validity Bit
–Set
–Clear
Select the vailidity bit.
Mode
–Consumer
– Professional
Select the AES3/SPDIF format.
Status Bits
–Channel
–User
Select the status bits type.
Edit Bits
(Consumer)
Select Byte Select the byte and edit the byte.
Audio Mode
– Non-Linear PCM
– Linear PCM
Select the audio mode.
Copyright
–Copyright
– Non-copyright
Select the copyright type.
Emphasis
– No pre-emphasis
– 50/15 ìs
– Reserved 1
– Reserved 2
Select the emphasis type.
Channel Mode 0 to 3 Set the channel mode value.
Table A-5 Digital generator menu tree description (continued)
Level 1 Level 2 Level 3 Level 4 Description
