Output Config
Ref Clock
Source
–Internal
– AES RCLK
–External
Select the reference clock source.
Type
–MCLK
–FSYNC
Select the external reference clock source.
Ref Clock
Word Length 8 to 32
Set the external reference clock word length
value.
Multiplier
Set the external reference clock multiplier value.
The selection available in the external reference
clock multiplier depends on the external
reference clock word length.
Sync Clock
Output
–On
–Off
Enable or disable the synchronous clock output.
Source
–Internal
– AES RCLK
–External
Select the synchronous clock source.
Divider
–1
–128
Select the synchronous clock divider value.
DSI Config
Voltage
– 1.2 Vpp
– 1.5 Vpp
– 1.8 Vpp
– 2.5 Vpp
–3 Vpp
– 3.3 Vpp
Select the output voltage or set your desired
output voltage.
Channels
–2
–4
–6
–8
–10
–12
–14
–16
Select the number of channels.
Format
–Left
–Right
–I2S
–DSP
Select the DSI output format.
Resolution 8 to 24 Set the audio resolution.
BClk Edge
– Rising
–Falling
Select the clock edge type.
Fsync Polarity
– Rising
–Falling
Select the sync polarity.
Table A-5 Digital generator menu tree description (continued)
Level 1 Level 2 Level 3 Level 4 Description
