Waveform Config
(Multitone)
Custom
Apply
Apply the current setting on the selected tone for
the custom multitone waveform.
Optimize
Optimize the crest factor for the custom multitone
waveform.
Frequency
Set the frequency value for the custom multitone
waveform.
Amplitude
Set the amplitude value for the custom multitone
waveform.
Phase
Set the phase value for the custom multitone
waveform.
Add Above
Add the tone above the selected tone for the
custom multitone waveform.
Add Below
Add the tone below the selected tone for the
custom multitone waveform.
Remove
Remove the selected tone for the custom
multitone waveform.
Clear
Clear all the tones in the custom multitone
waveform list.
Waveform Config
(Abitrary)
Amplitude Set the signal amplitude value.
DC Offset Set the signal DC offset value.
Load File
Load a waveform from a file.
Refer to “Appendix 13: Recall Menu Tree” on
page 494 for the recall menu tree.
Info Display the loaded waveform information.
Output Config
Connector
–Bal
–UnBal
Select the output connector type.
AES Output
–On
–Off
Enable or disable the AES output.
Optical Output
–On
–Off
Enable or disable the optical output.
Sample Rate Set the sample rate value.
Audio Format
– Linear PCM
– A-Law
– μ-Law
Select the encoding audio format.
Dither
–Off
– Rectangular
– Triangular
–Shaped
Select the dither type.
Table A-5 Digital generator menu tree description (continued)
