Filters Config
Clear Filters Clear all the filter settings.
LPF
–None
–2 kHz
–3 kHz
–5 kHz
–8 kHz
–10 kHz
–15 kHz
–20 kHz
–22 kHz
–30 kHz
–40 kHz
–50 kHz
–80 kHz
– Custom
Select the low-pass filter.
HPF
–None
–15 Hz
–20 Hz
–22 Hz
–30 Hz
–50 Hz
–70 Hz
–100 Hz
–200 Hz
–300 Hz
–400 Hz
– Custom
Select the high-pass filter.
Weighting
–None
–A
–CCIR 1k
–CCIR 2k
– C-Message
–CCITT
– Custom
Select the weighting filter.
Deemphasis
–None
–50 μs
–75 μs
– Custom
Select the filter de-emphasis value.
Notch Filter
State
Enable or disable the notch filter.
–Enable
– Disable
Center Freq Set the frequency of the component to be removed from the input signal.
Bandwidth Set the bandwidth of the signal component to be removed.
Table A-7 Analog analyzer menu tree description (continued)
Level 1 Level 2 Level 3 Description
