Appendixes A
Keysight U8903B User’s Guide 481
Filters Config
Clear Filters Clear all the filter settings.
LPF
–None
–15 kHz
–20 kHz
– Custom
– Select the low-pass filter.
HPF
–None
–22 Hz
–100 Hz
–400 Hz
– Custom
– Select the high-pass filter.
Weighting
–None
–A
–CCIR 1k
–CCIR 2k
– C-Message
–CCITT
– Custom
– Select the weighting filter.
Filters Config
Deemphasis
–None
–50 μs
–75 μs
– Custom
– Select the filter de-emphasis value.
Notch Filter
State
Enable or disable the notch filter.
–Enable
– Disable
Center Freq
Set the frequency of the component to be removed from
the input signal.
Bandwidth
Set the band width of the signal component to be
removed.
Table A-9 Bluetooth analyzer menu tree description (continued)
Level 1 Level 2 Level 3 Level 4 Description
