A Appendixes
482 Keysight U8903B User’s Guide
Meas Config
Coupling
–DC
–AC
Select the coupling type.
Sample Size
– 2048
– 4096
– 8192
– 16384
– 32768
– 65536
– 131072
– 262144
– 524288
Select the sample size.
Mov Average 1 to 20
Set the number of measurement readings to be used for
the moving average calculation.
Sync Average 1 to 64
Set the number of points for the synchronous averaging
in the analyzer meter mode.
Src Channel
Select the internal generator channel as the reference
channel used in the following situations.
For the result calculation in unit dBg.
For the frequencies searching algorithm when the
frequency lock is set to Gen Lock.
Trigger Trigger Source
–Free Run
–External
– Channel
Select the trigger source
Link Config Device Scan
Device Search
Search for the discoverable Bluetooth devices within
range.
Max Scan 1 to 16
Set the maximum number of Bluetooth devices to be
identified.
Filter Class
–All
– Custom
Select the filter class type.
Custom Set the Bluetooth device class.
Refresh Device
Refresh the friendly name of the selected Bluetooth
device.
Table A-9 Bluetooth analyzer menu tree description (continued)
Level 1 Level 2 Level 3 Level 4 Description
