A Appendixes
500 Keysight U8903B User’s Guide
IO Configuration Properties
Sub-Steps:
Send SCPI
Settings
– GPIB Address
Select the desired GPIB address.
– SCPI Commands
–Edit
Set the SCPI commands at the lower half of
the main display.
–Import
Load the SCPI commands from a file. Refer
to “Appendix 13: Recall Menu Tree” on
page 494 for the recall menu tree.
– Progress Msg
Set the optional text message that will be
displayed on a dialog box for the time length
set in Delay.
– Delay
Set the delay time length after the SCPI
command(s) is issued.
Properties Set the prompt sub-step name.
Measurement
Enable Enable or disable the selected measurement.
Add Measurement
–AC level
– Frequency
– Phase
–SNR
– THD+N
–DC level
–Crosstalk
– SMPTE IMD
– DFD IMD
– Multitone analyzer
–POLQA
– Stepped frequency sweep
– SMPTE frequency sweep
– DFD frequency sweep
– Stepped level sweep
– SMPTE level sweep
– DFD level sweep
– DC level sweep
– Receiver Sensitivity
– Measurement recorder
Add measurements.
Delete Measurement Delete the selected test measurement.
Edit
Move or copy the selected measurement, or paste
a copied measurement after the selected
measurement.
Settings
Configure the selected test measurement.
Refer to “Measurement settings” on page 503
for the respective test measurement settings.
Table A-14 Test sequence menu tree description (continued)
Tab Level 1 Level 2 Level 3 Description
