14 Parameter change-over
14.3 Configuring the motor data parameter list by means of parameterisation
798
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00120 Setting of motor overload (I²xt) 100.00 % C02246/1 C02246/2 C02246/3 C02246/4
C00234 Oscillation damping influence 5.00 % C02249/1 C02249/2 C02249/3 C02249/4
C00235 Oscillation damping filter time 32 ms C02250/1 C02250/2 C02250/3 C02250/4
C00236 Oscillation damping field weakening 14 C02251/1 C02251/2 C02251/3 C02251/4
C00254 Kp position controller 5.00 1/s C02252/1 C02252/2 C02252/3 C02252/4
C00273 Motor moment of inertia 0.00 kg cm^2 C02256/1 C02256/2 C02256/3 C02256/4
C00495 Speed sensor selection 0 C02260/1 C02260/2 C02260/3 C02260/4
C00576 SC: Field feedforward control 200 % C02261/1 C02261/2 C02261/3 C02261/4
C00577 SC: Vp field weakening controller 0.0010 C02262/1 C02262/2 C02262/3 C02262/4
C00578 SC: Tn field weakening controller 20.0 ms C02263/1 C02263/2 C02263/3 C02263/4
C00653/1 Sensibility - Setpoint feedforward control 0 C02264/1 C02264/2 C02264/3 C02264/4
C00905 Motor phase direction of rotation 0 C02272/1 C02272/2 C02272/3 C02272/4
C00909/1 Max. pos. speed 120.00 % C02273/1 C02273/2 C02273/3 C02273/4
C00909/2 Max. neg. speed 120.00 % C02273/5 C02273/6 C02273/7 C02273/8
C00910/1 Max. pos. output frequency 1000 Hz C02274/1 C02274/2 C02274/3 C02274/4
C00910/2 Max. neg. output frequency 1000 Hz C02274/5 C02274/6 C02274/7 C02274/8
C00915 Motor cable length 5.0 m C02275/1 C02275/2 C02275/3 C02275/4
C00916 Motor cable cross-section 6.00 mm^2 C02276/1 C02276/2 C02276/3 C02276/4
C00938 PSM: Maximum motor current field weakening 30.00 % C02278/1 C02278/2 C02278/3 C02278/4
C00939 Ultimate motor current 3000.0 A C02279/1 C02279/2 C02279/3 C02279/4
C00965 Max. motor speed 60000 rpm C02280/1 C02280/2 C02280/3 C02280/4
C00966 VFC: Time const. slip comp. 100 ms C02281/1 C02281/2 C02281/3 C02281/4
C00971/1 VFC: Controller limitation V/f +encoder 10.00 Hz C02284/1 C02284/2 C02284/3 C02284/4
C00971/2 VFC: Slip limitation V/f +encoder 100.00 Hz C02284/5 C02284/6 C02284/7 C02284/8
C00972 VFC: Vp V/f +encoder 0.100 Hz/Hz C02285/1 C02285/2 C02285/3 C02285/4
C00973 VFC: Ti V/f +encoder 100.0 ms C02286/1 C02286/2 C02286/3 C02286/4
C00975 VFC-ECO: Vp CosPhi controller 0.500 Hz/Hz C02287/1 C02287/2 C02287/3 C02287/4
C00976 VFC-ECO: Ti CosPhi controller 200.0 ms C02288/1 C02288/2 C02288/3 C02288/4
C00977 VFC-ECO: Minimum voltage V/f 20.00 % C02289/1 C02289/2 C02289/3 C02289/4
C00982 VFC-ECO: Voltage reduction ramp 0.8 s C02290/1 C02290/2 C02290/3 C02290/4
C00985 SLVC: Gain of field current controller 0.50 % C02291/1 C02291/2 C02291/3 C02291/4
C00986 SLVC: Gain of cross current controller 0.00 % C02292/1 C02292/2 C02292/3 C02292/4
C00987 Inverter motor brake: nAdd 80 rpm C02293/1 C02293/2 C02293/3 C02293/4
C00988 Inverter motor brake: PT1 filter time 0.0 ms C02294/1 C02294/2 C02294/3 C02294/4
C00990 Flying restart fct.: Activate 0 C02295/1 C02295/2 C02295/3 C02295/4
C00991 Flying restart fct.: Process 2 C02296/1 C02296/2 C02296/3 C02296/4
C00992 Flying restart: Start frequency 10 Hz C02297/1 C02297/2 C02297/3 C02297/4
C00993 Flying restart: Integration time 300.0 ms C02298/1 C02298/2 C02298/3 C02298/4
C00994 Flying restart: Current 25.00 % C02299/1 C02299/2 C02299/3 C02299/4
C00995/1 SLPSM: Controlled accelerating current 100.00 % C02300/1 C02300/2 C02300/3 C02300/4
C00995/2 SLPSM: Controlled standstill current 20.00 % C02300/5 C02300/6 C02300/7 C02300/8
C00996/1 SLPSM: Switching speed, closed-loop control 13.00 % C02301/1 C02301/2 C02301/3 C02301/4
C00996/2 SLPSM: Switching speed, open-loop control 8.00 % C02301/5 C02301/6 C02301/7 C02301/8
C00997 SLPSM: Filter cutoff frequency 5.00 % C02302/1 C02302/2 C02302/3 C02302/4
C00998/1 SLPSM: Filter time rotor position 3.0 ms C02303/1 C02303/2 C02303/3 C02303/4
C00998/2 SLPSM: Filter time actual speed value 5.0 ms C02303/5 C02303/6 C02303/7 C02303/8
C00999 SLPSM: PLL gain 400 % C02304/1 C02304/2 C02304/3 C02304/4
C01001/1 Manual entry of motor type 0 C02315/1 C02315/2 C02315/3 C02315/4
C02853/1 PSM: Lss saturation characteristic 100 % C02305/1 C02305/2 C02305/3 C02305/4
C02853/2 PSM: Lss saturation characteristic 100 % C02305/5 C02305/6 C02305/7 C02305/8
C02853/3 PSM: Lss saturation characteristic 100 % C02305/9 C02305/10 C02305/11 C02305/12
C02853/4 PSM: Lss saturation characteristic 100 % C02305/13 C02305/14 C02305/15 C02305/16
Code Name Lenze setting 1st value 2nd value 3rd value 4th value
