235
2. To delete all learned tags linked to a PIN code, enter the PIN code and then press
the Status key. A long beep is audible.
To delete a single tag from the outdoor keypad, press the status key in the tag
configuration mode and hold the tag in front of the tag reader. Two short beeps are
audible. Each unlearned tag extends the unlearning phase and leaves the tag
reader illuminated for further five seconds.
3. The learn mode ends after five seconds of idle time. Press the disarm button to
exit the tag configuration mode. The status LED does not light up red anymore.
4. Press the disarm button again twice to exit the installer mode as well.
Operate the outdoor keypad by means of tags
Make sure that the outdoor keypad is activated to make the entries.
1. Arm:
Press the Arm button and hold the learned tag in front of the tag reader. One
long audio signal sounds and the red status LED lights up
2. Disarm:
Press the Disarm button and hold the learned tag in front of the tag reader. Two
audio signals sound and the blue status LED lights up.
3. Activate Home mode:
Press the Home button and then 1, 2, or 3 to activate the required home mode
and hold the learned tag in front of the tag reader. Three audio signals sound and
the red status LED flashes four times. If you do not press any number after the
Home button, home mode 1 is automatically activated.
Activate dual-key functions:
The outdoor keypad features pre-defined dual key commands that allow you to trigger a
fire, panic, or medical alarm without entering a PIN code. To activate the dual key
functions, please proceed as follows:
First of all, define which alarm shall be triggered when a certain dual key function is used
in the menu “Sensors” “List” .
To activate the dual key function, please proceed as follows:
