258
thermostat may vary from the room temperature. In the thermostat control menu,
you
can therefore define a temperature offset between -2.5 °C and +2.5 °C.
Example:
If the radiator valve thermostat is installed under a windowsill where the
temperature is 2° warmer than in the rest of the room (20° at the windowsill, 18°
in the room), then, the temperature offset should be set to -2°.
Calculation:
Room temperature +18°C
Radiator valve thermostat V2 measures +20°C
18-20 = -2°C
Schedule setting:
Choose whether the schedule settings as defined below are to be activated or
deactivated
Schedule setting:
Schedule:
Choose the day for which the schedule settings from the drop-down menu shall
apply. By activating the schedule, the radiator valve thermostat is set to
automatic mode.
o Time:
Enter the time when the temperature specified as setpoint temperature
shall be transmitted to the radiator valve thermostat.
o Setpoint heating
Select the setpoint temperature from the drop-down menu that shall be
transmitted to the radiator valve thermostat.
o Delete:
Deletes the schedule settings for the selected day
o Copy:
Copies the schedule settings of the selected day to the days marked in
the check boxes
o Return:
Returns to the sensor list
Apply the settings by pressing “OK”, reject the changes by pressing “Reset”, or leave
the menu by pressing “back”.
Note:
You can only connect up to 20 radiator valve thermostats to the alarm panel.
The radiator valve thermostat may only be used in temperatures between -10°C and
+50°C and a maximal humidity of 85% (non-condensing).
Even if you only want to test the radiator valve thermostat, it is required to connect it
to a heater valve. Otherwise, the error message F2 (no valve installed) is displayed.
The currently measured temperature of the radiator valve thermostat is shown in the
XT alarm panel in the menu “Sensors” “List” “Status”.
Example:
1. Current temperature 10.5°C
2. Valve opened in percent 10% open
3. Setpoint temperature 5°C
