MacDon PW8 - Troubleshooting Alarms and Diagnostic Faults - Gleaner R65;R66;R75;R76 and S Series

215575 159 Revision B
4.9.8 Troubleshooting Alarms and Diagnostic Faults – Gleaner
®®
R65/R66/R75/R76
and S Series
Errors in the auto header height control (AHHC) system on Gleaner
®
R65/R66/R75/R76 and non-S9 S series combines
appear on a display on the combine ’ s Electronic Instrument Panel (EIP).
NOTE:
Refer to 4.10 Gleaner
®
S9 Series Combines, page 161 for information specific to Gleaner
®
S9 Series combines.
NOTE:
Changes may have been made to the combine controls or the display since this document was published. Refer to the
combine operator’s manual for updated information.

$
Figure 4.112: Tachometer
Display type:
Displayed on tachometer (A) as XX or XXX.
Displayed on LCD (A) as XXX cm or XX in.

$
%
&
'
(
)
Figure 4.113: Combine Heads-Up Display
AUTO HEADER HEIGHT CONTROL
