Table 5.1 Maintenance Schedule/Record (continued)
ACTION:
ü - Check
S - Lubricate
▲ - Change
100 Hours
S
Clean and grease driveshaft splines – refer to
Cleaning Driveline Splined Shaft, page 233.
S
Lubricate driveline slip-joint and clutch – refer to 5.3
Lubrication, page 220.
S
Lubricate auger drive chain and bearing – refer to 5.3
Lubrication, page 220.
S
Lubricate optional caster wheels (if installed) at
grease point – refer to 5.3 Lubrication, page 220.
ü
Check tire pressure – refer to 5.11.3 Inflating Tires,
page 316.
ü
Check wheel bolt torque – refer to 5.11.2 Installing
Wheel, page 315.
ü
Check loose fasteners – refer to 8.1 Torque
Specifications, page 333.
ü
Check bearings and seals – refer to 5.7.3 Draper Deck
Roller Bearings, page 269.
ü
Check pick-up fingers for wear – refer to 5.7.2 Draper
Fingers and Guides, page 267.
ü
Check height control sensor pivot points – refer to
4.3 Header Height Sensors, page 105.
End of Season
Clean and touch-up worn paint spots
Clean header
ü
Check header for wear
5.2.2 Preseason/Annual Service
Perform these procedures after taking the pick-up header out of storage.
CAUTION
• Review the operator's manual to refresh your memory on safety and operating procedures.
• Review all safety signs and other decals on the header and note any hazard areas.
• Ensure that all shields and guards are properly installed and secured. Never alter or remove safety equipment.
• Make certain that you understand and practice safe use of all controls. Know the capacities and operating
characteristics of the machine.
Perform the following procedures at the beginning of each operating season:
1. Lubricate the machine completely. For more information, refer to 5.3 Lubrication, page 220.
2. Perform all annual maintenance. For more information, refer to 5.2.1 Maintenance Schedule/Record, page 216.
