MacDon PW8 - Attaching Header to Challenger, Gleaner, and Massey Ferguson Combines

215575 51 Revision B
• Gleaner® R65, 66, 67, 75, 76, 77, and all S and A Series
• Massey Ferguson® 9005, and 9500 Series
Attaching Header to Challenger®, Gleaner®, and Massey Ferguson® Combines
Attach the header to the combine to be able to operate the header using the combine operator’s console.
DANGER
To avoid injury or death from unexpected start-up of the machine, always stop the engine and remove the key from
the ignition before leaving the operator’s seat for any reason.
DANGER
Check to be sure all bystanders have cleared the area.

$
%
Figure 3.51: Feeder House – All AGCO Combines
except Gleaner
®®
R and S Series

%
$
Figure 3.52: Feeder House – Gleaner
®®
R and S Series
1. Retract hooks (A) at the base of the feeder house using
tool (B). The tool is stored on the left side of the feeder
house when not in use.
OPERATION
