MacDon PW8 - Header In-Field Settings for Gleaner S9 Series Combine

215575 172 Revision B

$
Figure 4.139: AHHC on GSL
4. Press AHHC control switch (A) on the ground speed
lever (GSL) to engage the AHHC. The header positions itself
to the last-saved setpoint position.

$
Figure 4.140: Header Control Cluster
5. Use HEADER HEIGHT SETPOINT control dial (A) as necessary
to fine-tune the setpoint position.
4.10.5 Header In-Field Settings for Gleaner
®®
S9 Series Combine
Once the auto header height control (AHHC) system is working correctly with your Gleaner
®
S9 series combine, you can
fine-tune these AHHC settings to your liking.
NOTE:
Changes may have been made to the combine controls or the display since this document was published. Refer to the
combine operator’s manual for updated information.
AUTO HEADER HEIGHT CONTROL
