Chapter 2: Product Overview
Refer to this section to learn about the dimensions, weights, and equipment specifications for your pick-up header and its
systems.
2.1 Header Specifications
Consult this section to learn about the physical characteristics of and equipment specifications for your pick-up header.
Table 2.1 Header Specifications
Components Specifications
Frame and Structure
Width to edge of tires Refer to 2.2 Header Dimensions, page 19
Width (transport lights extended)
Refer to 2.2 Header Dimensions, page 19
Depth Refer to 2.2 Header Dimensions, page 19
Height (transport lights extended)
Refer to 2.2 Header Dimensions, page 19
Weight (not including completion packages) 1366 kg (3006 lb.)
Carrier
Case IH, New Holland, John Deere, AGCO, Versatile
Lighting Two amber transport
Manual storage Header-mounted storage case
Pick-up
Actual picking width Refer to 2.2 Header Dimensions, page 19
Draper width Refer to 2.2 Header Dimensions, page 19
Quantity of pick-up fingers
392
Draper drives
Two 97 cc (5.9 cu. in.) hydraulic motors
Auger
Diameter (including flighting)
615 mm (24 in.)
Tube diameter
410 mm (16 in.)
Quantity of fingers
13–22
Finger diameter
16 mm (5/8 in.) diameter induction hardened
Speed (combine dependent)
141–204 rpm
Driveline
Type
Heavy-duty PTO type, fully shielded with built-in clutch
Connections
Locking collar
