3.9 Changing Header Opening
Change the header opening of the pick-up header to configure it to operate with different combine makes and models.
To minimize setup at the dealership, PW8 Pick-Up Headers are factory-configured to suit a particular combine make,
model, and feeder house size. Each header configuration includes the parts and hardware needed to fit a different
combine model within the same brand family. Refer to the following chart to learn the specifications for your pick-up
header:
NOTE:
The conversion procedure is included in the Unloading and Assembly Instruction provided with the header.
NOTE:
You will need to purchase a Combine Completion Kit from your Dealer to make your pick-up header compatible with a
different make and model of combine.
Table 3.1 Combine Configurations
Factory Header Configuration Modified Header Configuration
Combine Make
Combine Model(s)
Feeder House Size
Combine Model(s)
Feeder House Size
Case IH
7010, 8010, 7120,
8120, 9120, 7230,
8230, 9230, 7240,
8240, and 9240
137.2 cm (54 in.)
5088, 6088, 7088,
5130, 6130, 7130,
5140, 6140, and 7140
115.6 cm (45 1/2 in.)
Challenger®
670
139.7 cm (55 in.)
660
111.8 cm (44 in.)
John Deere
9660 STS, 9760 STS,
9860 STS, 9670 STS,
9770 STS, 9870 STS,
S650, S660, S670,
S680, and S690
139.7 cm (55 in.)
9660 WTS and T670
166.4 cm (65 1/2 in.)
Massey Ferguson®
9790
139.7 cm (55 in.)
9690
111.8 cm (44 in.)
New Holland
CR970, CR980,
CR9070, CR9080,
CR8090, CR9090,
CR9090 Elevation,
CR8.90, CR9.90,
CR9.90 Elevation, and
CR10.90 Elevation
127.0 cm (50 in.)
CX840, CX860, CX880,
CX8070, CX8080,
CX8080 Elevation,
CX8090, and
CX8090 Elevation
157.5 cm (62 in.)
CR920, CR940, CR960,
CR9020, CR9040,
CR9060, CR9065,
CR6090, CR7090,
CR8080, CR6.90, and
CR7.90
101.6 cm (40 in.)
Versatile
RT490
111.8 cm (44 in.)
n/a n/a
