Detaching Header from Challenger®, Gleaner®, and Massey Ferguson® Combine
Be sure to place the header driveline on its storage bracket when detaching it from a Challenger®, Gleaner®, or Massey
Ferguson® combine.
WARNING
To avoid bodily injury or death from unexpected startup of machine, always stop the engine and remove the key from
the ignition before leaving the operator’s seat for any reason.
1. Drive the combine to a level area and position the header slightly off the ground.
2. Shut down the engine, and remove the key from the ignition.

%
$
&
'
Figure 3.65: Opening Receptacle
3. Lower handle (A) on header receptacle (B).
4. Push handle (C) on the combine receptacle to the fully
open position to release multicoupler (D).

%
$
Figure 3.66: Locking Coupler
5. Position multicoupler (A) onto the header receptacle, and
move handle (B) to the vertical position to lock the coupler.
