MacDon PW8 - Replacing Drive Roller Bearing on Left Side of Rear Deck

215575 270 Revision B
Replacing Drive Roller Bearing on Left Side of Rear Deck
The drive roller bearing on the left side of the rear deck is a non-greaseable type and can be found behind the rear deck
hydraulic motor. You may wish to replace the bearing support bushing at the same time.
WARNING
To avoid bodily injury or death from unexpected startup of machine, always stop the engine and remove the key from
the ignition before leaving the operator’s seat for any reason.
1. Lower the hold-down fully.
2. Lower header to the ground until the two float springs are loose.
3. Stop the engine, and remove the key from the ignition.
4. Release draper belt tension fully.

$
Figure 5.113: Wooden Block
5. Support the deck at both ends by placing a wooden
block (e.g. block [A]) under the frame close to the bearing.

$
Figure 5.114: Left Endshield
6. Open left endshield (A). Refer to 3.3.1 Opening Left
Endshield, page 25 for instructions.
MAINTENANCE AND SERVICING
