MacDon PW8 - Setting Maximum Work Height (New Holland CR Series)

215575 213 Revision B

$
Figure 4.226: New Holland Combine Display
3. Select the RUN tab that shows MANUAL HEIGHT.
NOTE:
The MANUAL HEIGHT field may appear on any of the RUN
tabs. When an auto height set point button is pressed, the
display will change to AUTO HEIGHT (A) as shown.
4. Lower the header to the ground.
5. Select one of auto height set point buttons shown in
Figure 4.224, page 212.
• Press SET 1 button for the lower position
• Press SET 2 button for the higher position
4.15.5 Setting Maximum Work Height (New Holland CR Series)
This procedure applies only to 2015 and later CR models (6.80, 6.90, 7.90, 8.90, 9.90, and 10.90).

$
Figure 4.227: New Holland Combine Display
1. Select TOOLBOX (A) on main page. The TOOLBOX page
appears.

$
%
Figure 4.228: New Holland Combine Display
2. Select FEEDER (A). The FEEDER SETUP page appears.
3. Select MAXIMUM WORK HEIGHT field (B).
AUTO HEADER HEIGHT CONTROL
