4.8.3 Calibrating Auto Header Height Control – Challenger
®®
6 Series
The auto header height control (AHHC) sensor output must be calibrated for Challenger
®
6 Series combines, or the AHHC
feature will not work properly.
NOTE:
Changes may have been made to the combine controls or the display since this document was published. For instructions,
refer to the combine operator’s manual for updated information.

Figure 4.92: Challenger
®®
Combine Display
1. On the FIELD page, select the DIAGNOSTICS icon. The
MISCELLANEOUS page appears.

$
Figure 4.93: Challenger
®®
Combine Display
2. Select CALIBRATIONS button (A). The CALIBRATIONS page
appears.
AUTO HEADER HEIGHT CONTROL
