2.3 Component Identification
Being able to identify the parts and systems of your pick-up header will make looking up content in its reference manuals
much easier.
Figure 2.3: PW8 Pick-Up Header

$
%
&
(
)
'
+
-
.
/
1
4
5
8
9
:
7
6
5
4
<
0
3
*
$
6
;
A - Transport Light B - Endshield (Fixed) C - Transition Frame
D - Stripper Plate E - Auger F - Auger Finger
G - Auger Pan H - Multicoupler Receptacle J - Driveline
K - Manual Case L - Endshield (Latched) M - Hold-Down Cylinder Safety Prop
N - Draper Drive Motor P - Hold-Down Lift Cylinder Q - Gauge Wheel
R - Reflector S - Handle T - Draper Finger
U - Hold-Down V - Hold-Down Fiberglass Rod W - Forward Draper Deck
X - Rear Draper Deck Y - Auger Flighting
