215575 222 Revision B
Every 100 Hours
$
%
&
Figure 5.4: Greasing Points
A - Driveline Slip-Joint B - Driveline Guard (Both Ends)
C - Driveline Clutch D - Optional Caster Wheel (Two Places)
NOTE:
The header illustration shows the factory-equipped fixed wheels. Caster wheels (D) are available as an optional kit, and
should be greased if equipped.
MAINTENANCE AND SERVICING
