215575 309 Revision B
Figure 5.207: Left Side of Header
6. Secure the hose with clips (A) and cinch straps (B).
Figure 5.208: Bottom Beam Cover
7. Install bottom beam cover (B) and tighten bolts (A).
8. Close the endshield. For instructions, refer to 3.3.2 Closing
Left Endshield, page 26.
9. Bleed the hydraulic cylinders and lines. For instructions,
refer to 5.9.4 Bleeding Cylinders and Lines, page 303.
MAINTENANCE AND SERVICING
