215575 331 Revision B
Problem Solution
Refer to
Symptom: Slave cylinder remains extended more than 13 mm (1/2 in.) when hold-down is fully lowered
Air in the hydraulic system Bleed the hydraulic cylinders.
5.9.4 Bleeding Cylinders and Lines,
page 303
Symptom: Hold-down remains raised and will not lower
The safety prop is engaged Disengage the safety prop.
3.5 Engaging Hold-Down Lift Cylinder
Safety Props, page 33
Hydraulics are not connected properly
Ensure that the hydraulic lines are
connected properly and are not
damaged.
5.9.5 Hydraulic Hoses and Lines, page
304
Symptom: Driveline clutch is slipping
The clutch is worn
Replace the clutch. Replacing Driveline Clutch, page 228
An obstruction is in auger
Shut off the combine, remove the key,
and remove the obstruction.
Refer to your header
operator’s manual.
Symptom: Pick-up header wheels bounce over bumps
The header is positioned too high
Lower the header until the rear pick-
up roller is 305 mm (12 in.) above
the ground.
• Header Height, page 90
• 3.12.4 Adjusting Header Float,
page 93
TROUBLESHOOTING
