MacDon PW8 - Page 47

215575 31 Revision B

$
%
%
$
&

%
$
$
%
&
Figure 3.15: Right Endshield
3. Position endshield (C) against the header frame, and install
nuts and bolts (B) to attach the upper endshield brackets to
the header frame. Do NOT tighten the nuts at this time.
4. Install nuts and bolts (A) to attach the lower endshield
brackets to frame.
5. Tighten all hardware.
