— 114 EW-CoM EW-Com
— Port See Chapter 7.18.1.
— 115 xBPI xBPI
— Port See Chapter 7.18.1.
— HS Hardware status
— 120 Slot 1 EMPtY = empty or PR 5510 card type
— 121 Slot 2 EMPtY = empty or PR 5510 card type
— 122 Slot 4 EMPtY = empty or PR 1721 card type
— 123 bAt bAt oK battery status
— Pd Pendeo search
— 124 SEArCH Search for Pendeo load cells and set dead load;
see Chapter 7.5.6.
— CA Filling mode, only for EasyFill
— 150 dModE Select filling mode
nE.t = Net filling (B1) or ne.t d.l. = Net decrease
(B4)
— IM Interaction mode, only for EasyFill
— 151 IModE Select interaction mode
See Chapter 8.2.2.
— PC Configure printout, only for EasyFill
— 160 nuMPrt Number of printouts
— 161 SEqnr Enter sequence number.
— 162 PrtMod Select printing mode.
LAyout = appl. layout or nICELb =
NiceLabelExpress
— 163…168 LAyou 1…6 Configure line 1…6.
nEt = net weight, GroSS = gross weight,
MAtnAM = material name, nonE = no printout,
FF = formfeed, SEq = sequence number, dAtE =
date and time, SEtP = set point, tArE = tare
weight, nL = CR/LF (carriage return and line
feed)
— do Configure digital outputs, only for EasyFill
— 170…172 out 1…3 Enter SPM addresses %MXxxx; see Chapter 13.4
— dI Configure digital inputs, only for EasyFill
— 174…176 InP 1…3 Enter SPM address %MXxxx; see Chapter 13.4
— ou Configure digital outputs (PR 5510/12), only for
EasyFill
— 180…191 out 1…12 Enter SPM address %MXxxx; see Chapter 13.4
— In Configure digital inputs (PR 5510/12), only for
EasyFill
— 192…197 out 1…6 Enter SPM address %MXxxx; see Chapter 13.4
Note:
The meaning of the individual data and parameters and the associated value ranges can
be found in the description of operation via Notebook/PC.
7 Getting started X3 Process Indicator PR 5410
Minebea Intec EN-129
