Function SPM Bit Description
limit 1 out X16 = 0 Limiting signal 1: not active
limit 2 out X17 = 0 Limiting signal 2: not active
limit 3 out X18 = 0 Limiting signal 3: not active
ADC error X32 = 0 General error in weighing point: not ac-
tive (no error)
above Max X33 = 0 Weight above Max: not active
overload X34 = 0 Weight above Max plus the 'overload'
value: not active
below zero X35 = 0 Weight not below zero
center zero X36 = 0 Weight not within ¼ d of zero
inside ZSR X37 = 0 Weight not within zero-setting range
standstill X38 = 0 Standstill not active
out (of range) X39 = 0 Weight not below zero or above Max
command error X48 = 0 For internal use only.
command busy X49 = 0 For internal use only.
power fail X50 = 0 Set after power-on (=power failure): not
active
test active X56 = 0 Analog test was not started.
cal active X57 = 0 For internal use only.
tare active X58 = 0 Instrument is not tared.
marker bit 1 X64 = 0 Marker bit 1 not set, after power-on the
markers are set to "0".
marker bit 2 X65 = 0 Marker bit 2 not set, after power-on the
markers are set to "0".
marker bit 3 X66 = 0 Marker bit 3 not set, after power-on the
markers are set to "0".
actual diginp1 X00 = 1 digital input 1: active
actual diginp2 X01 = 1 digital input 2: active
actual diginp3 X02 = 1 digital input 3: active
limit 1 out X16 = 1 Limiting signal 1: active
limit 2 out X17 = 1 Limiting signal 2: active
limit 3 out X18 = 1 Limiting signal 3: active
ADC error X32 = 1 General error in the weighing point
above Max X33 = 1 Weight above Max
overload X34 = 1 Weight above Max plus the 'overload'
value
below zero X35 = 1 Weight below zero
X3 Process Indicator PR 5410 7 Getting started
EN-254 Minebea Intec
