Input: 0 and 1 (e.g.: 111; 001)
An info window is shown briefly.
Input: 0 and 1 (e.g.: 111; 100)
3. Enter the input values using the keyboard and confirm.
The inputs are simulated to test the functionality of the PLC (application); see
Chapter
9.1.4.
An info window is shown briefly. The "Internal" test mode is active.
4. Press to return to the previous window.
5. Press the [Stop PLC] softkey.
6. Enter the output values using the keyboard and confirm.
The physical inputs and outputs (hardware) are tested without the involvement of
the PLC (application) (see Chapter
9.1.4).
An info window is shown briefly. The "External" test mode is active.
7. Press to return to the previous window.
9 Extended functions X3 Process Indicator PR 5410
Minebea Intec EN-293
