Example:
Relay control (power output)
Digital outputs
Inductive load for free-wheel diode
Supply unit U
DC
= 24 V 0.5 A
The relay switches when the output is active (true).
To protect the output circuit, relays must be equipped with free-wheel diodes.
4 Device installation X3 Process Indicator PR 5410
Minebea Intec EN-43
