14.3 Creating a Send Effect
Sometimes you may want to have a classic send effect, for example a reverb which can be
shared by multiple sound sources. To make use of a send effect, you need to:
â–ª Step 1: Set up a Sound or Group as send effect. This is done by loading an effect into its
first Plug-in slot: ↑14.3.1, Step 1: Set Up a Sound or Group as Send Effect.
â–ª Step 2: Route a portion of the desired audio signals from their original Sounds and Groups
to that send effect. This is done via the Output properties of the corresponding Sounds and
Groups: ↑14.3.2, Step 2: Route Audio to the Send Effect.
14.3.1 Step 1: Set Up a Sound or Group as Send Effect
The procedure to set up a Sound or Group as a send effect is straightforward: You just need to
load an effect into its first Plug-in slot — MASCHINE will take care of the rest and make it
available as destination for other channels of your Project!
The procedure in Arrange view is described here. You can also do this in Mix view — see section
↑14.1.1, Adding an Effect.
In this example we will use an empty Sound:
1. Choose the empty Sound you want to use as send effect: On the left of the Arranger click
the Group containing that Sound, on the left of the Pattern Editor click the desired Sound
slot, and click the SOUND tab in the top left corner of the Control area.
2. At the far left of the Control area, click the Plug-in icon to display the Plug-ins of the
Sound:
Using Effects
Creating a Send Effect
MASCHINE MIKRO - Manual - 656
