NEC iPASOLINK EX Advanced - Remove Registered RADIUS Server

3-66 SECURITY MANAGEMENT
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
3.14.3 Remove Registered RADIUS Server
Procedure 3-17
1. Launch and log in to WebLCT.
2. In the
MENU frame on the left, expand Network Management Setting, then its
submenu
Security Management to select RADIUS Setting. The RADIUS
Setting
window appears.
3. Click the
Clear RADIUS Server tool button.
Figure 3-88 RADIUS Setting Window
4. Clear RADIUS Server option window appears. Select the target RADIUS
Server number from the
No. drop-down list, then click the OK button.
Figure 3-89 Clear RADIUS Server Option Window
Clear RADIUS Server tool button
