4.9.2.2 Update Program File — RF Firmware
Important:
1. Ensure that the prepared Program File was supplied by NEC.
2. Check the current version of Program using the
Equipment Inventory
Information
window.
3. Put the system into the Maintenance Mode before beginning to download
the RF Program. Do not cancel the Maintenance mode while the download
is in progress.
Procedure 4-23 RF
1. Click the Maintenance tool button on the tool bar of the WebLCT to put the
system into the Maintenance Mode. The
MAINT indicator on the tool bar
changes to orange.
2. In the
MENU frame on the left, expand the Equipment Utility to select Update
(Storage -> NE) Utility
. The Update (Storage -> NE) Utility window appears.
3. Select
Program File by clicking its radio button, then click the Execute tool
button.
Figure 4-117 Update (Storage -> NE) Utility Window
Program File option window to select an object appears.
Execute tool button
Program File
