Set ETH Function 8-65
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
8.6.2 OAM MEP Tab
8.6.2.1 Add MEP Index
Procedure 8-19
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select ETH OAM Setting. The ETH OAM Setting window
appears.
3. In the OAM MEP tabbed page, click the Add MEP button.
Figure 8-87 ETH OAM Setting Window — OAM MEP Tab
OAM MEP Setting (Add)
option window appears.
To Next Page
