iPASOLINK EX Advanced: INSTALLATION GGS-000546-01E
2.4.2.2 DC PSE Unit
NOTE: DC PSE Unit does not convert the voltage. That is, the power voltage
of the power source will be applied as it is to iPASOLINK EX/A. When
connecting the DC PSE Unit, ensure to sue the power source that
can supply the stable power.
Figure 2-3 DC PSE Unit
2.4.3 Power Cable (SELV)
Figure 2-4 Power Cable (SELV; Double-Insulated)
2.4.4 LAN Cable (Electric)
Figure 2-5 LAN Cable (Electric; Double-Shielded, with Waterproofing Cap)
