5-44 CORRECTIVE MAINTENANCE
GGS-000548-01E iPASOLINK EX Advanced: OPERATION & MAINTENANCE
ETH
This condition indicates that the provided SFP Port type and the mounted SFP
Module do not match.
Procedure 5-32
1. Launch WebLCT, and display the Inventory window to check the port
configuration. Correct the setting(s) if any inappropriate setting is found.
2. Retrieve the Current Status, and check if the SFP Type Mismatch alarm is
cleared.
3. Is the SFP Type Mismatch alarm cleared?
YES: This step ends the procedure.
NO: Go to Step 4.
4. Check if the mounted SFP Module is the correct type for the port.
5. Is the type of SFP Module appropriate?
YES: Contact NEC.
NO: Replace SFP Module, and go to Step 6.
6. Retrieve the Current Status, and check if the SFP Type Mismatch alarm is
cleared. If the alarm is not cleared, contact NEC for the further maintenance
support.
This step ends the procedure.
ETH
This condition is not an alarm. The message indicates that the current status of speed
and duplex mode of the indicated port.
Equipment
This condition indicates that the received Sync Status Message is in the unstable
condition. The problem of this condition pertains to the input cable or to the external
timing source.
SFP Type Mismatch
Speed & Duplex
SSM Fail
To Next Page
