NEC iPASOLINK EX Advanced - ATPC Manual Control

4-30 CONTROL ITEMS
GGS-000548-01E iPASOLINK EX Advanced: Operation & Maintenance
4.5.1 ATPC Manual Control
Performing this function (Manual Control) sets the Maintenance Mode to ON.
However, in case of Auto setting and if Maintenance Mode is set to OFF, it will
cancel the "auto setting."
Procedure 4-10
1. Click the Maintenance tool button on the tool bar of the WebLCT to put the
system into the Maintenance Mode. The MAINT indicator on the tool bar
changes to orange.
2. In the
MENU frame on the left, expand the Maintenance Control to select
MODEM Maintenance Control. The MODEM Maintenance Control window
appears.
3. Click
Off link in the ATPC Manual Control option.
Figure 4-43 MODEM Maintenance Control Window
The MODEM Maintenance Control option window appears.
click
