NEC iPASOLINK EX Advanced - Traffic Interface Specifications and Standards; 1000 Base-X

SPECIFICATION 2-5
iPASOLINK EX Advanced: SPECIFICATION GGS-000549-01E
2.3 Traffic Interface Specifications and Standards
2.3.1 1000BASE-X
ITEM SPECIFICATIONS
Application IEEE802.3 Full Duplex
1000BASE-SX 1000BASE-LX
Nominal Bit Rate 1250 Mbit/s
Coding Method 8B/10B
Transmitter at Reference Point S
Operating Wavelength Range 770 to 860 nm 1270 to 1355 nm
SMSR 0.85 dB (RMS) 4 dB (RMS)
Maximum Mean Launched Power 0 dBm –3 dBm
Minimum Mean Launched Power –9.5 dBm –11 dBm
Minimum Extinction Ratio (dB) 9 dB or more 9 dB or more
Receiver at Reference Point R
Operating Wavelength Range 770 to 860 nm 1270 to 1355 nm
Maximum Mean Launched Power –17 dBm –19 dBm
Minimum Mean Launched Power –0 dBm –3 dBm
Others
Target Distance 550 m 5 km
Type of Fiber Cable MMF: GI Cable
(Core/Clad dia.: 50/125
µm)
SMF: SI Cable
(Core/Clad dia.: 9/125 µm)
Connector LC Connector using SFP
