NEC iPASOLINK EX Advanced - Update Controller Data

CONTROL ITEMS 4-87
iPASOLINK EX Advanced: OPERATION & MAINTENANCE GGS-000548-01E
4.9.2.5 Update Controller Data
NOTE: Proceeding through the following restarts the equipment, which terminates
the
WebLCT connection.
Important:
1. Ensure that the data file of Controller Data has already been on the site.
2.
Check the F/W versions using the Equipment Inventory Information window.
3. To operate the Controller data, the system must be set into the Maintenance
mode; Do not cancel the Maintenance mode while the download process is in
progress.
Procedure 4-26
1. Click the Maintenance tool button on the tool bar of the WebLCT to put the
system into the Maintenance Mode. The
MAINT indicator on the tool bar
changes to orange.
2. In the
MENU frame on the left, expand the Equipment Utility to select Update
(Storage -> NE) Utility
.
3. The
Update (Storage -> NE) Utility window appears. Select Controller Data
by clicking its radio button, and then click the Execute tool button.
Figure 4-142 Update (Storage -> NE) Utility Window
Execute tool button
Controller Data
