8-18 Set ETH Function
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
8.4 VLAN Setting
8.4.1 Add VLAN/S-VLAN ID
Procedure 8-5
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select VLAN Setting. The VLAN Setting window appears.
3. In the VLAN List tabbed page, click the Add VLAN ID button on the tool bar.
Figure 8-18 VLAN Setting Window — VLAN List Tab (example: 802.1q)
The Add VLAN ID option window appears.
VLAN List tab
Add VLAN ID tool button
