NEC iPASOLINK EX Advanced - ETH OAM Setting; Add MEG Index; OAM MEG Tab

Set ETH Function 8-57
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
8.6 ETH OAM Setting
 OAM: Operation, Administration & Maintenance

MEG: Maintenance Entity Group

MEP: MEG End Point

MIP: MEG Intermediate Point
8.6.1 OAM MEG Tab
8.6.1.1 Add MEG Index
Procedure 8-16
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select ETH OAM Setting. The ETH OAM Setting window
appears.
3. In the OAM MEG tabbed page, click the Add MEG tool button.
Figure 8-74 ETH OAM Setting Window — OAM MEG Tab
OAM MEG Setting (Add)
option window appears.
Add MEG tool button
