NEC iPASOLINK EX Advanced - Add MIP Index; OAM MIP Tab

Set ETH Function 8-75
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
8.6.3 OAM MIP Tab
8.6.3.1 Add MIP Index
Procedure 8-22
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select ETH OAM Setting. The ETH OAM Setting window
appears.
3. In the OAM MIP tabbed page, click the Add MIP tool button.
Figure 8-104 ETH OAM Setting Window — OAM MIP Tab
OAM MIP Setting (Add)
option window appears.
OAM MIP tab
Add MIP tool button
