3-18 ROUTINE MAINTENANCE
GGS-000548-01E IPASOLINK EX ADVANCED: OPERATION & MAINTENANCE
3.3.7.3 MODEM RF BBE TCN Threshold
Table 3-10 MODEM RF BBE TCN Threshold (Sheet 1 of 2)
Modulation Type 15 Min TCN Threshold 24H TCN Threshold
CS Modulation Range Default Threshold Range Default Threshold
Detect Recovery detect Recovery
62.5 MHz QPSK 1 to 6671000 66710 6671 1 to 640416000 6404160 640416
8PSK 1 to 10006000 100060 10006 1 to 960576000 9605760 960546
16QAM 1 to 13342000 133420 13342 1 to 1280832000 12808320 1280832
32QAM 1 to 16677000 166770 16677 1 to 1600992000 16009920 1600992
64QAM 1 to 20013000 200130 20013 1 to 1921248000 19212480 1921248
128QAM 1 to 23349000 233490 23349 1 to 22415040 22415040 2241504
256QAM 1 to 26684000 266840 26684 1 to 2561664000 25616640 2561664
125 MHz QPSK 1 to 13265000 132650 13256 1 to 1273440000 12734400 1273440
8PSK 1 to 19898000 198980 19898 1 to 1910208000 19102080 1910208
16QAM 1 to 26531000 265310 26531 1 to 2546976000 25469760 2546976
32QAM 1 to 33164000 331640 33164 q to 3183744000 31837440 3183744
64QAM 1 to 39797000 397970 39797 1 to 3820512000 38205120 3820512
128QAM 1 to 46430000 464300 46430 1 to 4457280000 44572800 4457280
256QAM 1 to 53062000 530620 53062 1 to 5093952000 50939520 5093652
250 MHz QPSK 1 to 26563000 265630 36563 1 to 2550048000 25500480 2550048
8PSK 1 to 39845000 398450 39845 1 to 3825120000 38251200 3825120
16QAM 1 to 53126000 531260 53126 1 to 5100096000 51000960 5100096
32QAM 1 to 66408000 664080 66408 1 to 6375168000 63751680 6375168
64QAM 1 to 79690000 796900 79690 1 to 7650240000 76502400 7650240
128QAM 1 to 92971000 929710 92971 1 to 8925216000 89252160 8925216
256QAM 1 to 106253000 1062530 106253 1 to 10200288000 102002880 12022088
500 MHz QPSK q to 53306000 533060 53306 1 to 5117376000 51173760 5117376
8PSK 1 to 79959000 799590 79959 1 to 7676064000 76760640 7676064
16QAM 1 to 106612000 1066120 106612 1 to 10234752000 102347520 10234752
32QAM 1 to 133265000 1332650 133265 1 to 12793440000 127934400 12793440
64QAM 1 to 159918000 1599180 159918 1 to 15352128000 153521280 15352128
128QAM 1 to 186572000 1865720 186572 1 to 17910912000 179109120 17910912
256QAM 1 to 213225000 2132250 213225 1 to 20469600000 204696000 20469600
