NEC iPASOLINK EX Advanced - 2.3 Available Systems and Components

COMPOSITIONS 2-3
iPASOLINK EX Advanced: INSTALLATION GGS-000546-01E
2.3 Available Systems and Components
2.3.1 1+0 System
NOTE: SELV (Safety Extra Low Voltage).
CONTENTS QTY DESCRIPTION
iPASOLINK EX/A 1 TRP-80G10GB-1A: NWA-A01926
[2.4.1, Figure 2-1]
Power Injector 1
SELV
NOTE
PoE++:
AC PSE Unit: NWA-A00086 [2.4.2.1, Figure 2-2]
DC PSE Unit: NWA-A00087 [2.4.2.2, Figure 2-3]
Power Cable 1
SELV
NOTE
; Double-insulated; with Waterproofing Cap.
[2.4.3, Figure 2-4]
LAN Cables (Electric) 1 For P1 Port; RJ-45; Double-shielded; with Waterproofing Cap.
[2.4.4, Figure 2-5]
LAN Cables (Optic) 1 or 2 For P2 and P3 Ports; LC; with Waterproofing Cap.
[2.4.5, Figure 2-6]]
Grounding Cable 1 EX/A must be grounded. [2.4.6, Figure 2-7]
Antenna and its Mounting
Bracket
1[2.4.7, Figure 2-8]
