COMPOSITIONS 2-1
iPASOLINK EX Advanced: INSTALLATION GGS-000546-01E
2. COMPOSITIONS
2.1 Overview
Following shows the list of contents; iPASOLINK EX/A and its parts required to set
up iPASOLINK EX/A. Confirm them before starting the installation.
2.2 Power Supply and Circuit Breaker
Since iPASOLINK EX/A itself does not have a power on/off switch, it requires a
circuit breaker or shut-off function externally. See the following for reference.
Normal Connection (to DC –48 V Port)
DC –48V
EXTERNAL CIRCUIT BREAKER
POWER CABLE
EX/A
(2-Core Shielded Cable of
14 to 16 AWG)
To Next Page
