NEC iPASOLINK EX Advanced - ETH Port Setting

8-14 Set ETH Function
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
8.3 ETH Port Setting
Procedure 8-4
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select ETH Port Setting. The ETH Port Setting window
appears.
3. Click the desired Port No. to configure.
Figure 8-13 ETH Port Setting Window
ETH Port Setting
option window appears.
Port No.
