NEC iPASOLINK EX Advanced - Delete MIP Index

Set ETH Function 8-81
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
8.6.3.3 Delete MIP Index
Procedure 8-24
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select ETH OAM Setting. The ETH OAM Setting window
appears.
3. In the OAM MIP tabbed page, click on the Delete MIP tool button.
Figure 8-112 ETH OAM Setting Window — OAM MIP Tab
4. OAM MIP Setting (Delete) option window appears. Select the MIP Index number
of the target, then click the
OK button.
Figure 8-113 OAM MIP Setting (Delete) Option Window
OAM MIP tab
Delete MIP tool button
