NEC iPASOLINK EX Advanced - Delete Entry

NETWORK MANAGEMENT 5-47
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
5.6.2.3 Delete Entry
Procedure 5-17
1.
Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Network Management to select IP
Access Control Setting
. The IP Access Control Setting window appears.
3. In the Forwarding Filter List tabbed page, click the Delete Entry tool button on
the tool bar.
Figure 5-69 IP Access Control Setting Window
4. Forwarding Filter Entry (Delete) option window appears. Enter the Entry No. of
the target, then click the
OK button.
Figure 5-70 Forwarding Filter Entry (Delete) Option Window
Confirmation
dialog box appears.
Forwarding Filter List tab
Delete Entry tool button
