NEC iPASOLINK EX Advanced - Delete MEG Index

Set ETH Function 8-63
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
8.6.1.3 Delete MEG Index
Procedure 8-18
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then expand ETH Function
Setting
to select ETH OAM Setting. The ETH OAM Setting window appears.
3. Select the OAM MEG tab, then click the Delete MEG tool button.
Figure 8-82 ETH OAM Setting Window — OAM MEG Tab
OAM MEG Setting (Delete)
option window appears.
4. Enter the MEG Index number of the target to be removed, then click the OK
button.
Figure 8-83 OAM MEG Setting (Delete) Option Window
Delete MEG tool button
