NEC iPASOLINK EX Advanced - P2;P3 Port (SFP+)

5-10 CONNECT CABLES
GGS-000546-01E iPASOLINK EX Advanced: INSTALLATION
5.5.2 P2/P3 Port (SFP+)
Each LAN cable to connect with iPASOLINK EX/A should wear a waterproofing
cap. Following shows the connecting method of LAN Cable with SFP+ and
waterproofing cap:
 Reference
1. Uncover the protected port. Waterproofing cap can be off by turning it counter-
clockwise.
Figure 5-15 Remove Waterproofing Cap
