2-4 COMPOSITIONS
GGS-000546-01E iPASOLINK EX Advanced: INSTALLATION
2.4 Components Appearances
2.4.1 iPASOLINK EX/A Main Part
Figure 2-1 iPASOLINK EX/A (for 1+0 Configuration Only)
2.4.2 Power Injector
2.4.2.1 AC PSE Unit
Figure 2-2 AC PSE Unit
(FRONT VIEW)
(PORT-SIDE VIEW)
(NWA-A00086)
